High telecentricity, ultra-low distortion, high cost performance
High resolution supports 5MP 2/3″ camera
Adopt double telecentric (object side, image side) design
Proprietary identification of features such as integrated circuits, glass, LCD panels, etc.
Easy for automated high speed operations.
Parameters
| EFL | Coaxial Illumination | Sensor size | 2/3″ |
| Magnification（x） | 0.2x | MOD | 110 |
| F.NO | 7.8 | Numerical aperture | 0.022 |
| Telecentric degree | <0.1° | TV Distortion | ﹤0.05% |
| Depth of field | 8.78 | Object Resolution | 27.96um |
| TTL | 155.7 | Mount | C-Mount |
| 2/3″FOV(D×H×V) | 55×44×33 | Magnification | 0.2 |
| WD | 110mm |
Large image circle, suitable for IMX253LLR(1.1’’ 12MP)
EFL range from 16mm to 75mm
Magnification range from 0.03×-0.8×
Ultra-low distortion(<0.05%)
High contrast, low distortion
Support 1.4″ sensor, compatible with 4/3″, 1.1″ sensor
Optical structure optimization for large size chip, with standard C-mount
Excellent performance at any working distance
Support multiple communication modes: RS232 / pulse
Autofocus accuracy ± 0.001 degree
The response time is less than 1ms
EFL covers 8-50mm
