High telecentricity, ultra-low distortion, high cost performance
High resolution supports 5MP 2/3″ camera
Adopt double telecentric (object side, image side) design
Proprietary identification of features such as integrated circuits, glass, LCD panels, etc.
Easy for automated high speed operations.
Parameters
| EFL | None- coaxial Illumination | Sensor size | 2/3″ |
| Magnification（x） | 1.5x | MOD | 110 |
| F.NO | 12 | Numerical aperture | 0.06 |
| Telecentric degree | <0.1° | TV Distortion | ﹤0.05% |
| Depth of field | 0.24 | Object Resolution | 5.59um |
| TTL | 148.2 | Mount | C-Mount |
| 2/3″FOV(D×H×V) | 7.3×5.9×4.4 | Magnification | 1.5 |
| WD | 110mm |
Fixed aperture, manual adjustable aperture is optional
The TV distortion is less than 0.1%
Series focal length covers 4-75mm
Compact design
High contrast industrial FA lens
Fixed aperture, manual adjustable aperture is optional
The TV distortion is less than 0.1%
Series focal length covers 4-75mm
Compact design
High contrast industrial FA lens
Fixed aperture, manual adjustable aperture is optional
The TV distortion is less than 0.1%
Series focal length covers 4-75mm
Compact design
High contrast industrial FA lens
