Standards
| Model | TS2M8SXGV-409M/C |
| Sensor | IMX421 |
| Image Mode | Mono/Color |
| Optical Size | 10.94mm |
| Resolution | 1936 * 1472 |
| Pixel Size | 4.5μm * 4.5μm |
| Max Frame Rate | 409.165 fps |
| Bit Depth | 8/10/12 bit |
| Dynamic Range | ≥72 dB |
| Data Rate | 1166 MB/s (8bit) |
| Trigger Mode | Free Run / External Trigger |
| Trigger Source | Software Trigger / External IO |
| Exposure Control | Pulse Width Control, Timed |
| Exposure Time | 6μs-10s(Step: 1μs) |
| Analog Gain | 0-24dB |
| Digital Gain | 0.004-8.000x |
| Lens Mount | C Mount |
| Data Interface | 10GigE |
| Power Connector | HR10A-10R-12PB(71)(Male) |
| Power Supply | DC12-24V(±10%) 2.0A |
| Power Consumption | 15.4 W |
| Dimensions | 70.0mm(W) x 70.0mm(H) x 73.2mm(D)(Without adapter) |
| Operating Temperature | 0-55℃ |
| Storage Temperature | -20-75℃ |
