Description
Parameters
| F.NO | 3.8-16 | TV Distortion | 0.0005% |
| Magnification Range | 0.93-1.07 | Standard Magnification | 1 |
| O/I | 439.45 | Flange Distance | 209.47 |
| Mount | V-Mount（φ49） | Filter Size | M45×P0.5 |
| Focal length | 116 | Max image circle | φ82 |
| WD | 184.16 |
Additional information
| Line Focus length | 116mm |
|---|---|
| Line Resolution | 16K |
| Line Magnification range | 0.93x-1.07x |
| Line Mount | V-Mount (φ49) |
| Line Filter thread | M45×P0.5 |
