Description
Illumination Type: Non-Coaxial
Sensor: 1.1″
Magnification: 0.345x
WD: 200mm
F.NO: 8.2
Nd: 0.021
Telecentricity: ﹤0.07°
TV distortion: ﹤0.05%
DOF(mm): 3.100
Object-Side Resolution: 15.98um
TTL: 194.4
Mount: C-Mount
FOV(D×H×V): 50.8×41.1×30
Size: φ77×176.9
Additional information
| Illumination Type | Non-Coaxial |
|---|---|
| Sensor | 1.1" |
| Magnification | 0.345x |
| WD | 200mm |
| F.NO | 8.2 |
| Nd | 0.021 |
| Telecentricity | ﹤0.07° |
| TV distortion | ﹤0.05% |
| DOF(mm) | 3.100 |
| Object-Side Resolution | 15.98um |
| TTL | 194.4 |
| Mount | C-Mount |
| FOV(D×H×V) | 50.8×41.1×30 |
| Size | φ77×176.9 |
