High telecentricity, ultra-low distortion, high cost performance
High resolution supports 5MP 2/3″ camera
Adopt double telecentric (object side, image side) design
Proprietary identification of features such as integrated circuits, glass, LCD panels, etc.
Easy for automated high speed operations.
Parameters
| EFL | None- coaxial Illumination | Sensor size | 2/3″ |
| Magnification（x） | 0.2x | MOD | 110 |
| F.NO | 7.8 | Numerical aperture | 0.022 |
| Telecentric degree | <0.1° | TV Distortion | ﹤0.05% |
| Depth of field | 8.78 | Object Resolution | 27.96um |
| TTL | 152.4 | Mount | C-Mount |
| 2/3″FOV(D×H×V) | 55×44×33 | Magnification | 0.2 |
Ultra high imaging quality
Matches the IMX226 sensor
Series focal length covers 6-50mm
Compact, super compact design
Fixed aperture, manual adjustable aperture is optional
The TV distortion is less than 0.1%
Series focal length covers 4-75mm
Compact design
High contrast industrial FA lens
Fixed aperture, manual adjustable aperture is optional
The TV distortion is less than 0.1%
Series focal length covers 4-75mm
Compact design
High contrast industrial FA lens
Match SONY high pixel sensor IMX492
Support 1.4″ sensor, compatible with 4/3″, 1.1″ sensor
Optical structure optimization for large size sensors, with standard C-Mount
Excellent performance at any working distance
