Description
Parameters
| EFL | None- coaxial Illumination | Sensor size | 2/3″ |
| Magnification（x） | 4x | MOD | 110 |
| F.NO | 22 | Numerical aperture | 0.09 |
| Telecentric degree | <0.1° | TV Distortion | ﹤0.05% |
| Depth of field | 0.062 | Object Resolution | 3.73um |
| TTL | 127.76 | Mount | C-Mount |
| 2/3″FOV(D×H×V) | 2.75×2.5×1.65 | Magnification | 4 |
| WD | 110mm |
Additional information
| Tc Illumination Type | Non-Coaxial |
|---|---|
| Tc Sensor | 2/3" |
| Tc Magnification | 4x |
| Tc Telecentricity | ﹤0.1° |
| Tc Mount | C-Mount |
