Description
Parameters
| EFL | Coaxial Illumination | Sensor size | 2/3″ |
| Magnification（x） | 0.2x | F.NO | 6 |
| Numerical aperture | 0.022 | Telecentric degree | ﹤0.15° |
| TV Distortion | 0.1% | Depth of field | 6.75 |
| Object Resolution | 22.37um | TTL | 140.81 |
| Mount | C-Mount | 2/3″FOV(D×H×V) | 55×44×33 |
| Magnification | 0.2 | WD | 65mm |
Additional information
| Illumination Type | Coaxial |
|---|---|
| Sensor | 2/3" |
| Magnification | 0.2x |
| WD | 65mm |
| F.NO | 6 |
| Nd | 0.022 |
| Telecentricity | ﹤0.15° |
| TV distortion | ﹤0.1% |
| DOF(mm) | 6.75 |
| Object-Side Resolution | 22.37um |
| TTL | 140.81 |
| Mount | C-Mount |
| 2/3 inch FOV(D×H×V) | 55×44×33 |
| 1/1.8 inch FOV(H×V) | 44.5×36×26.5 |
| 1/2 inch FOV(H×V) | 40×32×24 |
| Size | φ68×123.28 |
| Weight（g) | 306 |
