High telecentricity, ultra-low distortion, high cost performance
High resolution supports 5MP 2/3″ camera
Adopt double telecentric (object side, image side) design
Proprietary identification of features such as integrated circuits, glass, LCD panels, etc.
Efor automated high speed operations
Parameters
| EFL | Coaxial Illumination | Sensor size | 2/3″ |
| Magnification（x） | 0.3x | MOD | 65 |
| F.NO | 6.7 | Numerical aperture | 0.022 |
| Telecentric degree | ﹤0.15° | TV Distortion | ﹤0.05% |
| Depth of field | 3.35 | Object Resolution | 15.25um |
| TTL | 150.39 | Mount | C-Mount |
| 2/3″FOV(D×H×V) | 36.7×29.3×22 | Magnification | 0.3 |
Fixed aperture, manual adjustable aperture is optional
The TV distortion is less than 0.1%
Series focal length covers 4-75mm
Compact design
High contrast industrial FA lens
Match SONY high pixel sensor IMX492
Support 1.4″ sensor, compatible with 4/3″, 1.1″ sensor
Optical structure optimization for large size sensors, with standard C-Mount
Excellent performance at any working distance
Support 1.4″ sensor, compatible with 4/3″, 1.1″ sensor
Optical structure optimization for large size chip, with standard C-mount
Excellent performance at any working distance
Fixed aperture, various aperture available
Supports 1/1.7″ , 2/3 “and 1.1″ chips respectively
Suitable for high vibration and high impact
environment such as robot arms
