Description
Parameters
| EFL | Coaxial Illumination | Sensor size | 2/3″ |
| Magnification（x） | 0.75x | MOD | 65 |
| F.NO | 9.5 | Numerical aperture | 0.04 |
| Telecentric degree | <0.1° | TV Distortion | ﹤0.1% |
| Depth of field | 0.760 | Object Resolution | 8.39um |
| TTL | 105.1 | Mount | C-Mount |
| 2/3″FOV(D×H×V) | 14.6×11.7×8.8 | Weight | 95.11 |
| Magnification | 0.75 | WD | 65mm |
Additional information
| Tc Illumination Type | Coaxial |
|---|---|
| Tc Sensor | 2/3" |
| Tc Magnification | 0.75x |
| Tc Telecentricity | ﹤0.1° |
| Tc Mount | C-Mount |
