Description
Parameters
| EFL | None- coaxial Illumination | Sensor size | 2/3″ |
| Magnification（x） | 1x | MOD | 65 |
| F.NO | 11 | Numerical aperture | 0.045 |
| Telecentric degree | <0.1° | TV Distortion | ﹤0.1% |
| Depth of field | 0.495 | Object Resolution | 7.46um |
| TTL | 108.14 | Mount | C-Mount |
| 2/3″FOV(D×H×V) | 11×8.8×6.6 | Weight | 86.89 |
| Magnification | 1 |
Additional information
| Tc Illumination Type | Non-Coaxial |
|---|---|
| Tc Sensor | 2/3" |
| Tc Magnification | 1x |
| Tc Telecentricity | ﹤0.1° |
| Tc Mount | C-Mount |
