Description
Parameters
| EFL | Coaxial Illumination | Sensor size | 2/3″ |
| Magnification（x） | 4x | MOD | 65 |
| F.NO | 18 | Numerical aperture | 0.112 |
| Telecentric degree | ﹤0.05° | TV Distortion | <0.03% |
| Depth of field | 0.051 | Object Resolution | 3um |
| TTL | 122.12 | Mount | C-Mount |
| 2/3″FOV(D×H×V) | 2.75×2.5×1.65 | Magnification | 4 |
| WD | 65mm |
Additional information
| Tc Illumination Type | Coaxial |
|---|---|
| Tc Sensor | 2/3" |
| Tc Magnification | 4x |
| Tc Telecentricity | ﹤0.05° |
| Tc Mount | C-Mount |
