Description
Parameters
| EFL | None- coaxial Illumination | Sensor size | 2/3″ |
| Magnification（x） | 6x | MOD | 65 |
| Numerical aperture | 0.112 | Telecentric degree | ﹤0.05° |
| TV Distortion | ﹤0.05% | Depth of field | 0.03 |
| Object Resolution | 3um | TTL | 143.4 |
| Mount | C-Mount | 2/3″FOV(D×H×V) | 1.8×1.5×1.1 |
| Magnification | 6 | WD | 65mm |
Additional information
| Tc Illumination Type | Non-Coaxial |
|---|---|
| Tc Sensor | 2/3" |
| Tc Magnification | 6x |
| Tc Telecentricity | ﹤0.05° |
| Tc Mount | C-Mount |
