Standards
| Model | TS12MCL-65M/C |
| Sensor Type | Global Shutter CMOS |
| Image Mode | Color / Mono |
| Optical Size | 28.16 mm |
| Resolution | 4096 * 3072 |
| Pixel Size | 5.5μm * 5.5μm |
| Max Frame Rate | 65.28fps@8bit，52.53fps@10bit |
| Bit Depth | 8/10 bit |
| Dynamic Range | ≥54dB |
| Data Rate | 826MB/s |
| Trigger Mode | Free run / External trigger |
| Trigger Source | External IO / Camera Link CC1 |
| Exposure Control | Program / Pulse Width |
| Exposure Time | 26µs-1s (step: 10µs@8bit, 12µs@10bit) |
| Analog Gain | 1/2/3/4x |
| Digital Gain | 0.01-8.00x |
| Lens Mount | M42 / F Mount |
| Data Interface | Camera Link |
| Power interface | Hirose HR10A-7R-6PB(Male) |
| Power Supply | DC12-24V(±10%) 1A |
| Power Consumption | 6.9 W |
| Dimensions | 80mm x 80mm x 35.2mm (Without adapter) |
| Operating Temperature | 0-55℃ |
| Storage Temperature | -20-75℃ |
