Description
Standards
| Model | TS8MSCXP10-194U |
| Sensor | Global Shutter CMOS |
| Image Mode | Mono |
| Optical Size | 11.04 mm |
| Resolution | 2848 * 2848 |
| Pixel Size | 2.74μm * 2.74μm |
| Max Frame Rate | FastExposureMode ON: 193.66fps@8bit, 174.01fps@10bit, 127.21fps@12bit FastExposureMode OFF: 192.14fps@8bit, 172.79fps@10bit, 126.55fps@12bit |
| Bit Depth | 8/10/12 bit |
| Dynamic Range | ≥69.5 dB |
| Data Rate | 1548 MB/s |
| Trigger Mode | Free run / External trigger |
| Trigger Source | External IO / CXP Trigger |
| Exposure Control | Pulse Width Control, Timed |
| Exposure Time | 8.7μs-10s(Step:0.0135μs) |
| Analog Gain | 0-24dB |
| Digital Gain | 0.001-8.000x |
| Lens Mount | M58 * 0.75 |
| Data Interface | CoaXPress10 |
| Power Connector | Hirose HR10A-7R-6PB(Male) |
| Power Supply | DC12-24V(±10%) 1.0A |
| Power Consumption | 7.0 W |
| Dimensions | 80.0mm(W) x 80.0mm(H) x 75.4mm(D) |
| Operating Temperature | 0-55℃ |
| Storage Temperature | -20-75℃ |
Additional information
| Area Scan Data Interface | CXP10 |
|---|---|
| Area Resolution | 8MP |
| Horizontal Resolution | 2,848 |
| Vertical Resolution | 2,848 |
| Area Mono/Color | Mono |
| Rate (kHz/fps) | 193.66 |
| Pixel Size (μm) | 2.74 |
| Area Scan Sensor | IMX487 |
| Area Sensor Type | Global CMOS |
| Lens Mount | M58 |
