Description
Illumination Type: Non-Coaxial
Sensor: 1.1″
Magnification: 0.3x-0.8x
WD: 110mm
F.NO: 2.7-7.2
Nd: 0.055
Telecentricity: 3.4°-8.5°
TV distortion: ﹤0.2%
Relative Illuminance: ﹥80%
Object Resolution: 6.1um
DOF(mm): 1.2-0.43
TTL: 212.416
Filter thread: M43×P0.75
Size: φ76×205.89
Additional information
| Illumination Type | Non-Coaxial |
|---|---|
| Sensor | 1.1" |
| Magnification | 0.3x-0.8x |
| WD | 110mm |
| F.NO | 2.7-7.2 |
| Nd | 0.055 |
| Telecentricity | 3.4°-8.5° |
| TV distortion | ﹤0.2% |
| Relative Illuminance | ﹥80% |
| Object Resolution | 6.1um |
| DOF(mm) | 1.2-0.43 |
| TTL | 212.416 |
| Filter thread | M43×P0.75 |
| Size | φ76×205.89 |
