Description
Parameters
| F.NO | 4.5-16 | TV Distortion | ﹤0.01% |
| Magnification Range | 0.04-0.1 | Standard Magnification | 0.08 |
| O/I | 574.5 | Flange Distance | 37.42 |
| Mount | V-Mount（φ38） | Filter Size | M37×P0.75 |
| Focal length | 35 | Max image circle | φ30 |
| WD | 508.49 |
Additional information
| Line Focus length | 35mm |
|---|---|
| Line Resolution | 4K |
| Line Magnification range | 0.04x-0.1x |
| Line Mount | V-Mount (φ38) |
| Line Filter thread | M37×P0.75 |
