Description
Illumination Type: Non-Coaxial
Sensor: 1.1″
Magnification: 0.3x
WD: 110mm
F.NO: 6.5
Nd: 0.023
Telecentricity: ﹤0.05°
TV distortion: ﹤0.05%
DOF(mm): 3.250
Object-Side Resolution: 15um
TTL: 178
Mount: C-Mount
1.1 inch FOV(D×H×V): 58.6×47.2×34.5
13 inch FOV(H×V): 42.7×32
2/3 inch FOV(H×V): 29.3×22
Size: φ76×160.4
Additional information
| Tc Illumination Type | Non-Coaxial |
|---|---|
| Tc Sensor | 1.1" |
| Tc Magnification | 0.3x |
| Tc Telecentricity | ﹤0.05° |
| Tc Mount | C-Mount |
