Description
Illumination Type: Non-Coaxial
Sensor: 2/3″
Magnification: 0.2x
WD: 275mm
F.NO: 8.8
Nd: 0.0115
Telecentricity: ﹤0.05°
TV distortion: ﹤0.05%
DOF(mm): 9.900
Object-Side Resolution: 29.17um
TTL: 198.92
Mount: C-Mount
FOV(D×H×V): 54.8×43.8×32.8
Size: φ80×181.4
Additional information
| Illumination Type | Non-Coaxial |
|---|---|
| Sensor | 2/3" |
| Magnification | 0.2x |
| WD | 275mm |
| F.NO | 8.8 |
| Nd | 0.0115 |
| Telecentricity | ﹤0.05° |
| TV distortion | ﹤0.05% |
| DOF(mm) | 9.900 |
| Object-Side Resolution | 29.17um |
| TTL | 198.92 |
| Mount | C-Mount |
| FOV(D×H×V) | 54.8×43.8×32.8 |
| Size | φ80×181.4 |
