Description
Parameters
| F.NO | 4.0-16 | TV Distortion | ﹤0.5% |
| Magnification Range | 0.03-0.35 | Standard Magnification | 0.2 |
| O/I | 355.39 | Flange Distance | 12 |
| Mount | M72×P0.75 | Filter Size | M62×P0.75 |
| Focal length | 45 | Max image circle | φ62 |
| WD | 223.5 |
Additional information
| Line Focus length | 45mm |
|---|---|
| Line Resolution | 8K |
| Line Magnification range | 0.03x-0.35x |
| Line Mount | M72×P0.75 |
| Line Filter thread | M62×P0.75 |
