Description
Parameters
| EFL | Coaxial Illumination | Sensor size | 2/3″ |
| Magnification（x） | 0.8x | MOD | 110 |
| F.NO | 8.9 | Numerical aperture | 0.045 |
| Telecentric degree | ﹤0.15° | TV Distortion | ﹤0.1% |
| Depth of field | 0.55 | Object Resolution | 7.46um |
| TTL | 148.5 | Mount | C-Mount |
| 2/3″FOV(D×H×V) | 13.7×11×8.2 | Magnification | 0.8 |
| WD | 110mm |
Additional information
| Tc Illumination Type | Coaxial |
|---|---|
| Tc Sensor | 2/3" |
| Tc Magnification | 0.8x |
| Tc Telecentricity | ﹤0.15° |
| Tc Mount | C-Mount |
