Description
Illumination Type: Non-Coaxial
Sensor: 1/1.8″
Magnification: 0.123x
WD: 200mm
F.NO: 4.6
Nd: 0.013
Telecentricity: 0.08°
TV distortion: ﹤0.05%
DOF(mm): 13.682
Object-Side Resolution: 25.81um
TTL: 190.16
Mount: C-Mount
FOV(D×H×V): 70.7×57.3×43
Size: φ98×170.6
Additional information
| Illumination Type | Non-Coaxial |
|---|---|
| Sensor | 1/1.8" |
| Magnification | 0.123x |
| WD | 200mm |
| F.NO | 4.6 |
| Nd | 0.013 |
| Telecentricity | 0.08° |
| TV distortion | ﹤0.05% |
| DOF(mm) | 13.682 |
| Object-Side Resolution | 25.81um |
| TTL | 190.16 |
| Mount | C-Mount |
| FOV(D×H×V) | 70.7×57.3×43 |
| Size | φ98×170.6 |
