Description
Parameters
| EFL | Coaxial Illumination | Sensor size | 2/3″ |
| Magnification（x） | 1.5x | MOD | 65 |
| F.NO | 12 | Numerical aperture | 0.063 |
| Telecentric degree | <0.1° | TV Distortion | ﹤0.1% |
| Depth of field | 0.24 | Object Resolution | 5.33um |
| TTL | 90.3 | Mount | C-Mount |
| 2/3″FOV(D×H×V) | 13.8×11×8.2 | Magnification | 1.5 |
| WD | 65mm |
Additional information
| Illumination Type | Coaxial |
|---|---|
| Sensor | 2/3" |
| Magnification | 1.5x |
| WD | 65mm |
| F.NO | 12 |
| Nd | 0.063 |
| Telecentricity | ﹤0.1° |
| TV distortion | ﹤0.1% |
| DOF(mm) | 0.24 |
| Object-Side Resolution | 5.33um |
| TTL | 90.3 |
| Mount | C-Mount |
| 2/3 inch FOV(D×H×V) | 7.3×5.8×4.4 |
| 1/1.8 inch FOV(H×V) | 4.8×3.53 |
| 1/2 inch FOV(H×V) | 4.27×3.2 |
| Size | φ27×72.774 |
| Weight（g) | 88.87 |
