Description
Illumination Type: Non-Coaxial
Sensor: φ44
Magnification: 3x
WD: 110mm
F.NO: 9-88
Nd: 0.17
Telecentricity: ﹤0.05°
TV distortion: ﹤0.05%
DOF(mm): 0.405
Object-Side Resolution: 2um
TTL: 314
Mount: M58×P0.75
Flange distance: 11.48
FOV(D×H×V): 14.4×12×8
Size: φ65×302.51
Coating band: 420-680nm
Additional information
| Tc Illumination Type | Non-Coaxial |
|---|---|
| Tc Sensor | φ44 |
| Tc Magnification | 3x |
| Tc Telecentricity | ﹤0.05° |
| Tc Mount | M58×P0.75 |
