Description
Illumination Type: Non-Coaxial
Sensor: φ44
Magnification: 4x
WD: 110mm
Nd: 0.17
Telecentricity: ﹤0.05°
TV distortion: ﹤0.05%
DOF(mm): 0.54
Object-Side Resolution: 2um
TTL: 340.4
Mount: M58×P0.75
Flange distance: 11.48
FOV(D×H×V): 10.8×9×6
Size: φ65×328.92
Coating band: 420-680nm
Additional information
| Tc Illumination Type | Non-Coaxial |
|---|---|
| Tc Sensor | φ44 |
| Tc Magnification | 4x |
| Tc Telecentricity | ﹤0.05° |
| Tc Mount | M58×P0.75 |
