Description
Focus length: 10mm
Sensor: 1.4″
Magnification: 20x
WD: 20mm
Numerical Aperture: 0.45
Object Resolution: 0.75um
DOF: 2.47um
Wavelength: 420-1100nm
Objective Mount: M26×P0.706
1.4 inch FOV(H×V): 0.954×0.65
1.1 inch FOV(H×V): 0.705×0.53
2/3 inch FOV(H×V): 0.44×0.33
1/2 inch FOV(H×V): 0.32×0.24
Size: φ38.6×75
Additional information
| WD | 20mm |
|---|---|
| Numerical Aperture | 0.45 |
| Object Resolution | 0.75um |
| DOF | 2.47um |
| 1.1 inch FOV(H×V) | 0.705×0.53 |
| Size | φ38.6×75 |
| Micro Focus length | 10mm |
| Micro Sensor | 1.4" |
| Micro Magnification | 20x |
| Micro Objective Mount | M26×P0.706 |
