Description
Focus length: 200mm
Sensor: 1.4″
Magnification: 1x
WD: 14.5mm
Numerical Aperture: 0.05
Object Resolution: 6.71um
DOF: 110um
Wavelength: 420-680nm
Objective Mount: M26×P0.706
1.4 inch FOV(H×V): 19.08×13.08
1.1 inch FOV(H×V): 14.1×10.6
2/3 inch FOV(H×V): 8.8×6.6
1/2 inch FOV(H×V): 6.4×4.8
Size: φ36.8×80.5
Additional information
| Focus length | 200mm |
|---|---|
| Sensor | 1.4" |
| Magnification | 1x |
| WD | 14.5mm |
| Numerical Aperture | 0.05 |
| Object Resolution | 6.71um |
| DOF | 110um |
| Wavelength | 420-680nm |
| Objective Mount | M26×P0.706 |
| 1.4 inch FOV(H×V) | 19.08×13.08 |
| 1.1 inch FOV(H×V) | 14.1×10.6 |
| 2/3 inch FOV(H×V) | 8.8×6.6 |
| 1/2 inch FOV(H×V) | 6.4×4.8 |
| Size | φ36.8×80.5 |
