Description
Illumination Type: Non-Coaxial
Sensor: 2/3″
Magnification: 0.188x
WD: 167mm
F.NO: 6.8-40
Nd: 0.0138
Telecentricity: 0.08°
TV distortion: 0.014%
DOF(mm): 8.658
Object-Side Resolution: 24.31um
TTL: 244.7
Mount: C-Mount
FOV(D×H×V): 58.46×46.86×35.16
Size: φ76×227.17
Weight（g): 766.96
Additional information
| Illumination Type | Non-Coaxial |
|---|---|
| Sensor | 2/3" |
| Magnification | 0.188x |
| WD | 167mm |
| F.NO | 6.8-40 |
| Nd | 0.0138 |
| Telecentricity | 0.08° |
| TV distortion | 0.014% |
| DOF(mm) | 8.658 |
| Object-Side Resolution | 24.31um |
| TTL | 244.7 |
| Mount | C-Mount |
| FOV(D×H×V) | 58.46×46.86×35.16 |
| Size | φ76×227.17 |
| Weight（g) | 766.96 |
